SESDONCAN1LT3G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SESDONCAN1LT3G |
|---|---|
| حجم فایل | 72.573 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت SESDONCAN1LT3G |
دانلود دیتاشیت |
|---|
سایر مستندات
ESDONCAN1, SESDONCAN1 5 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: onsemi SESDONCAN1LT3G
- Clamping Voltage@Ipp: 50V
- Operating Temperature: -55°C~+150°C@(Tj)
- Breakdown Voltage (VBR): 26.2V
- Peak Pulse Power(Ppp)@8/20us: -
- Junction Capacitance(Cj)@1MHz: 10pF@1MHz
- Reverse Stand-Off Voltage (Vrwm): 24V
- Package: SOT-23-3
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Type: Zener
- Bidirectional Channels: 2
- Voltage - Reverse Standoff (Typ): 24V (Min)
- Voltage - Breakdown (Min): 26.2V
- Voltage - Clamping (Max) @ Ipp: 50V
- Current - Peak Pulse (10/1000µs): 3A (8/20µs)
- Power - Peak Pulse: -
- Power Line Protection: No
- Applications: Automotive, CAN
- Capacitance @ Frequency: 10pF @ 1MHz
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3 (TO-236)
- Base Part Number: SESDON
- detail: 50V Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
