50A02CH 数据手册
其他文档
50A02CH-TL-E 7 pages
技术规格
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Transistor Type: PNP
- Current - Collector (Ic) (Max): 500mA
- Voltage - Collector Emitter Breakdown (Max): 50V
- Vce Saturation (Max) @ Ib, Ic: 120mV @ 10mA, 100mA
- Current - Collector Cutoff (Max): 100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 200 @ 10mA, 2V
- Power - Max: 700mW
- Frequency - Transition: 690MHz
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: 3-CPH
- Base Part Number: 50A02
- detail: Bipolar (BJT) Transistor PNP 50V 500mA 690MHz 700mW Surface Mount 3-CPH
