NCV8177AMX250TCG Datasheet
Datasheet specifications
| Datasheet's name | NCV8177AMX250TCG |
|---|---|
| File size | 86.201 KB |
| File type | |
| Number of pages | 14 |
Download Datasheet NCV8177AMX250TCG |
Download Datasheet |
|---|
Other documentations
NCV8177 13 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi NCV8177AMX250TCG
- Package: DFN-4(1x1)
- Manufacturer: onsemi
- Series: Automotive, AEC-Q100
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 2.5V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.26V @ 500mA
- Current - Output: 500mA
- Current - Quiescent (Iq): 90µA
- PSRR: 75dB (1kHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 4-XDFN Exposed Pad
- Supplier Device Package: 4-XDFN (1x1)
- Base Part Number: NCV8177
- detail: Linear Voltage Regulator IC 1 Output 500mA 4-XDFN (1x1)
