NLU1G86CMUTCG دیتاشیت

NLU1G86CMUTCG

مشخصات دیتاشیت

نام دیتاشیت NLU1G86CMUTCG
حجم فایل 61.431 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

مشاهده دیتاشیت NLU1G86CMUTCG

دانلود دیتاشیت

سایر مستندات

NLU1G86 7 pages

مشخصات فنی

  • RoHS: true
  • Category: Logic ICs/Gates
  • Datasheet: onsemi NLU1G86CMUTCG
  • Sink Current: 8mA
  • Source Current: 8mA
  • Supply Voltage: 1.65V~5.5V
  • Logic Gate Type: XORGate
  • Number of Channels: 1
  • Operating Temperature: -55°C~+125°C
  • Propagation Delay Time: 8.8ns@5V,50pF
  • Quiescent Current (Max): 1uA
  • Package: DFN-6(1x1)
  • Manufacturer: onsemi
  • Series: MiniGate™
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Logic Type: XOR (Exclusive OR)
  • Number of Circuits: 1
  • Number of Inputs: 2
  • Features: -
  • Voltage - Supply: 1.65V ~ 5.5V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: 8mA, 8mA
  • Logic Level - Low: -
  • Logic Level - High: -
  • Max Propagation Delay @ V, Max CL: 8.8ns @ 5V, 50pF
  • Mounting Type: Surface Mount
  • Supplier Device Package: 6-UDFN (1x1)
  • Package / Case: 6-UFDFN
  • Base Part Number: NLU1G86
  • detail: XOR (Exclusive OR) IC 1 Channel 6-UDFN (1x1)
