دیتاشیت NCP717CMX285TBG

NCP717

مشخصات دیتاشیت

نام دیتاشیت NCP717
حجم فایل 557.225 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت NCP717

NCP717 Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Pre-ordered transistors
  • Datasheet: onsemi NCP717CMX285TBG
  • Package: DFN-4(1x1)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 2.85V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.265V @ 300mA
  • Current - Output: 300mA
  • Current - Quiescent (Iq): 35µA
  • PSRR: -
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 4-XDFN Exposed Pad
  • Supplier Device Package: 4-XDFN (1x1)
  • Base Part Number: NCP717
  • detail: Linear Voltage Regulator IC 1 Output 300mA 4-XDFN (1x1)
