NSVT3904DXV6T1G دیتاشیت

NSVT3904DXV6T1G

مشخصات دیتاشیت

نام دیتاشیت NSVT3904DXV6T1G
حجم فایل 78.428 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت NSVT3904DXV6T1G

دانلود دیتاشیت

سایر مستندات

NST(V)3904DXV6T(1,5), SNST3904DXV6T5G 8 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
  • Datasheet: onsemi NSVT3904DXV6T1G
  • Transistor Type: 2 NPN
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Collector Current (Ic): 200mA
  • Power Dissipation (Pd): 500mW
  • Transition Frequency (fT): 300MHz
  • DC Current Gain (hFE@Ic,Vce): 100@10mA,1V
  • Collector Cut-Off Current (Icbo): -
  • Collector-Emitter Breakdown Voltage (Vceo): 40V
  • Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 300mV@50mA,5mA
  • Package: SOT-563
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Current - Collector (Ic) (Max): 200mA
  • Voltage - Collector Emitter Breakdown (Max): 40V
  • Vce Saturation (Max) @ Ib, Ic: 300mV @ 5mA, 50mA
  • Current - Collector Cutoff (Max): -
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 10mA, 1V
  • Power - Max: 500mW
  • Frequency - Transition: 300MHz
  • Mounting Type: Surface Mount
  • Package / Case: SOT-563, SOT-666
  • Supplier Device Package: SOT-563
  • Base Part Number: NSVT39
  • detail: Bipolar (BJT) Transistor Array 2 NPN (Dual) 40V 200mA 300MHz 500mW Surface Mount SOT-563
