NLVHC1G00DFT2G دیتاشیت

NLVHC1G00DFT2G

مشخصات دیتاشیت

نام دیتاشیت NLVHC1G00DFT2G
حجم فایل 75.679 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

مشاهده دیتاشیت NLVHC1G00DFT2G

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • RoHS: true
  • Series: 74HC
  • Category: Logic ICs/Gates
  • Datasheet: onsemi NLVHC1G00DFT2G
  • Sink Current: 2.6mA
  • Source Current: 2.6mA
  • Supply Voltage: 2V~6V
  • Logic Gate Type: NAND Gates
  • Number of Channels: 1
  • Low Level Range (VIL): 0.1V~0.26V
  • Operating Temperature: -55°C~+125°C
  • High Level Range (VIH): 2V~5.8V
  • Propagation Delay Time: 17ns@6V,50pF
  • Quiescent Current (Max): 1uA
  • Package: SC-88A
  • Manufacturer: onsemi
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Logic Type: NAND Gate
  • Number of Circuits: 1
  • Number of Inputs: 2
  • Features: -
  • Voltage - Supply: 2V ~ 6V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: 2.6mA, 2.6mA
  • Logic Level - Low: 0.1V ~ 0.26V
  • Logic Level - High: 2V ~ 5.8V
  • Max Propagation Delay @ V, Max CL: 17ns @ 6V, 50pF
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-88A (SC-70-5/SOT-353)
  • Package / Case: 5-TSSOP, SC-70-5, SOT-353
  • Base Part Number: NLVHC1
  • detail: NAND Gate IC 1 Channel SC-88A (SC-70-5/SOT-353)
