NLVVHC1G86DFT1G دیتاشیت

NLVVHC1G86DFT1G

مشخصات دیتاشیت

نام دیتاشیت NLVVHC1G86DFT1G
حجم فایل 81.754 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

مشاهده دیتاشیت NLVVHC1G86DFT1G

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • RoHS: true
  • Series: 74VHC
  • Category: Logic ICs/Gates
  • Datasheet: onsemi NLVVHC1G86DFT1G
  • Sink Current: 8mA
  • Source Current: 8mA
  • Supply Voltage: 2V~5.5V
  • Logic Gate Type: XORGate
  • Number of Channels: 1
  • Low Level Range (VIL): 0.5V~1.65V
  • Operating Temperature: -55°C~+125°C
  • High Level Range (VIH): 1.5V~3.85V
  • Propagation Delay Time: 8.8ns@5V,50pF
  • Quiescent Current (Max): 1uA
  • Package: SC-88A
  • Manufacturer: onsemi
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Logic Type: XOR (Exclusive OR)
  • Number of Circuits: 1
  • Number of Inputs: 2
  • Features: -
  • Voltage - Supply: 2V ~ 5.5V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: 8mA, 8mA
  • Logic Level - Low: 0.5V ~ 1.65V
  • Logic Level - High: 1.5V ~ 3.85V
  • Max Propagation Delay @ V, Max CL: 8.8ns @ 5V, 50pF
  • Mounting Type: Surface Mount
  • Supplier Device Package: 6-UDFN (1.2x1)
  • Package / Case: 6-UFDFN
  • Base Part Number: NLVVHC1
  • detail: XOR (Exclusive OR) IC 1 Channel 6-UDFN (1.2x1)
