NCP130 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP130
|
|
حجم فایل
|
149.078
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
RoHS:
true
-
Feature:
Overcurrent Protection;Thermal Protection;欠压锁定(UVLO)
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCP130AMX080TCG
-
Output Current:
300mA
-
Output Voltage:
0.8V
-
Dropout Voltage:
0.15V@(300mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+85°C@(Ta)
-
Power Supply Rejection Ratio (PSRR):
80dB@(1kHz)
-
Package:
DFN-6(1.2x1.2)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
0.8V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.15V @ 300mA
-
Current - Output:
300mA
-
PSRR:
80dB ~ 65dB (1kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Under Voltage Lockout (UVLO)
-
Mounting Type:
Surface Mount
-
Package / Case:
6-XFDFN Exposed Pad
-
Supplier Device Package:
6-XDFN (1.2x1.2)
-
Base Part Number:
NCP130
-
detail:
Linear Voltage Regulator IC 1 Output 300mA 6-XDFN (1.2x1.2)
