SZMA3075WALT1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SZMA3075WALT1G
|
|
حجم فایل
|
96.513
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Zener Diodes
-
Datasheet:
onsemi SZMA3075WALT1G
-
Tolerance:
-
-
Power Dissipation:
225mW
-
Diode Configuration:
1 Pair Common Anode
-
Zener Voltage (Nom):
7.5V
-
Zener Impedance (Zzt):
-
-
Zener Voltage (Range):
7.2V~7.9V
-
Reverse Leakage Current (Ir):
60uA@6.5V
-
Package:
SOT-23(TO-236)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Type:
Zener
-
Unidirectional Channels:
2
-
Voltage - Reverse Standoff (Typ):
6.5V
-
Voltage - Breakdown (Min):
7.2V
-
Voltage - Clamping (Max) @ Ipp:
-
-
Current - Peak Pulse (10/1000µs):
-
-
Power - Peak Pulse:
15W
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
80pF @ 1MHz
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3 (TO-236)
-
Base Part Number:
MA3075
-
detail:
Clamp Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
