دیتاشیت ES2DAF

ES2DAF

مشخصات دیتاشیت

نام دیتاشیت ES2DAF
حجم فایل 165.158 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت ES2DAF

ES2DAF Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: onsemi ES2DAF
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 200V
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Forward Voltage (Vf@If): 950mV@2A
  • Reverse Leakage Current: 1uA@200V
  • Reverse Recovery Time (trr): 35ns
  • Average Rectified Current (Io): 2A
  • Package: DO-214AD
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 200V
  • Current - Average Rectified (Io): 2A
  • Voltage - Forward (Vf) (Max) @ If: 950mV @ 2A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 1µA @ 200V
  • Capacitance @ Vr, F: 30pF @ 4V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: DO-214AD, SMAF
  • Supplier Device Package: DO-214AD (SMAF)
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Base Part Number: ES2
  • detail: Diode Standard 200V 2A Surface Mount DO-214AD (SMAF)
