دیتاشیت NCP718BSN120T1G
مشخصات دیتاشیت
| نام دیتاشیت |
NCP718
|
| حجم فایل |
412.935
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
10
|
مشخصات
-
RoHS:
true
-
Feature:
Overcurrent Protection;Thermal Protection
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCP718BSN120T1G
-
Output Current:
300mA
-
Output Voltage:
1.2V
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
24V
-
Operating Temperature:
-40°C~+125°C@(Tj)
-
Quiescent Current (Ground Current):
8uA
-
Power Supply Rejection Ratio (PSRR):
60dB@(1kHz)
-
Package:
TSOT-23-5
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
24V
-
Voltage - Output (Min/Fixed):
1.2V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
-
-
Current - Output:
300mA
-
Current - Quiescent (Iq):
8µA
-
Current - Supply (Max):
300µA
-
PSRR:
60dB (1kHz)
-
Control Features:
Soft Start
-
Protection Features:
Over Current, Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-23-5 Thin, TSOT-23-5
-
Supplier Device Package:
TSOT-23-5
-
Base Part Number:
NCP718
-
detail:
Linear Voltage Regulator IC 1 Output 300mA TSOT-23-5
