دیتاشیت MCH6336-TL-W
مشخصات دیتاشیت
| نام دیتاشیت |
MCH6336
|
| حجم فایل |
566.353
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
RoHS:
true
-
Type:
P Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi MCH6336-TL-W
-
Operating Temperature:
+150°C@(Tj)
-
Power Dissipation (Pd):
1.5W
-
Total Gate Charge (Qg@Vgs):
6.9nC@4.5V
-
Drain Source Voltage (Vdss):
12V
-
Input Capacitance (Ciss@Vds):
660pF@6V
-
Continuous Drain Current (Id):
5A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.4V@1mA
-
Reverse Transfer Capacitance (Crss@Vds):
155pF@6V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
33mΩ@4.5V,3A
-
Package:
SOT-363-6(SC-70-6)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
FET Type:
P-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
12V
-
Current - Continuous Drain (Id) @ 25°C:
5A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
1.8V, 4.5V
-
Rds On (Max) @ Id, Vgs:
43mOhm @ 3A, 4.5V
-
Vgs(th) (Max) @ Id:
1.4V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
6.9nC @ 4.5V
-
Vgs (Max):
±10V
-
Input Capacitance (Ciss) (Max) @ Vds:
660pF @ 6V
-
FET Feature:
-
-
Power Dissipation (Max):
1.5W (Ta)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SC-88FL/MCPH6
-
Package / Case:
6-SMD, Flat Leads
-
Base Part Number:
MCH63
-
detail:
P-Channel 12V 5A (Ta) 1.5W (Ta) Surface Mount SC-88FL/MCPH6
