ESD8708MUTAG دیتاشیت

ESD8708MUTAG

مشخصات دیتاشیت

نام دیتاشیت ESD8708MUTAG
حجم فایل 75.841 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

مشاهده دیتاشیت ESD8708MUTAG

دانلود دیتاشیت

سایر مستندات

ESD8708 9 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: onsemi ESD8708MUTAG
  • Breakdown Voltage: 4V
  • Maximum Clamping Voltage: 6.8V
  • Reverse Stand-Off Voltage (Vrwm): 3.3V@Max
  • Peak Pulse Current (Ipp)@10/1000us: -
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: -
  • Package: DFN-14(1.5x5.5)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 8
  • Voltage - Reverse Standoff (Typ): 3.3V (Max)
  • Voltage - Breakdown (Min): 4V
  • Voltage - Clamping (Max) @ Ipp: 6.8V
  • Current - Peak Pulse (10/1000µs): 6.5A (8/20µs)
  • Power - Peak Pulse: -
  • Power Line Protection: No
  • Applications: Ethernet
  • Capacitance @ Frequency: 0.34pF @ 1MHz
  • Operating Temperature: -55°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 14-PowerUFDFN
  • Supplier Device Package: 14-UDFN (5.5x1.5)
  • Base Part Number: ESD87
  • detail: 6.8V Clamp 6.5A (8/20µs) Ipp Tvs Diode Surface Mount 14-UDFN (5.5x1.5)
