دیتاشیت SZCM1214A-01SO
مشخصات دیتاشیت
| نام دیتاشیت |
CM1214A
|
| حجم فایل |
364.979
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Datasheet:
onsemi SZCM1214A-01SO
-
Clamping Voltage@Ipp:
11.3V
-
Operating Temperature:
-40°C~+85°C@(Ta)
-
Breakdown Voltage (VBR):
-
-
Peak Pulse Power(Ppp)@8/20us:
-
-
Junction Capacitance(Cj)@1MHz:
-
-
Reverse Stand-Off Voltage (Vrwm):
7V
-
Package:
SOT-23(TO-236)
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q101
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Type:
Zener
-
Bidirectional Channels:
1
-
Voltage - Reverse Standoff (Typ):
7V
-
Voltage - Breakdown (Min):
-
-
Voltage - Clamping (Max) @ Ipp:
11.3V (Typ)
-
Current - Peak Pulse (10/1000µs):
1A (8/20µs)
-
Power - Peak Pulse:
-
-
Power Line Protection:
No
-
Applications:
Automotive, Ethernet, RF Antenna
-
Capacitance @ Frequency:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3 (TO-236)
-
Base Part Number:
SZCM12
-
detail:
11.3V (Typ) Clamp 1A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
