دیتاشیت EFC4621R-TR
مشخصات دیتاشیت
| نام دیتاشیت |
EFC4621R
|
| حجم فایل |
317.065
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
RoHS:
true
-
Type:
2 N-Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi EFC4621R-TR
-
Operating Temperature:
+150°C@(Tj)
-
Power Dissipation (Pd):
1.6W
-
Total Gate Charge (Qg@Vgs):
29nC@4.5V
-
Drain Source Voltage (Vdss):
24V
-
Input Capacitance (Ciss@Vds):
-
-
Continuous Drain Current (Id):
9A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.3V@1mA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
10.8mΩ@4.5V,3A
-
Package:
EFCP
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
FET Type:
2 N-Channel (Dual)
-
FET Feature:
Logic Level Gate, 2.5V Drive
-
Drain to Source Voltage (Vdss):
-
-
Current - Continuous Drain (Id) @ 25°C:
-
-
Rds On (Max) @ Id, Vgs:
-
-
Vgs(th) (Max) @ Id:
-
-
Gate Charge (Qg) (Max) @ Vgs:
29nC @ 4.5V
-
Input Capacitance (Ciss) (Max) @ Vds:
-
-
Power - Max:
1.6W
-
Mounting Type:
Surface Mount
-
Package / Case:
4-XFBGA, FCBGA
-
Supplier Device Package:
EFCP1616-4CE-022
-
Base Part Number:
EFC4621
-
detail:
Mosfet Array 2 N-Channel (Dual) 1.6W Surface Mount EFCP1616-4CE-022
