- دیتاشیت MBR8H100MFS, NRVB8H100MFS
MBR8H100MFS, NRVB8H100MFS دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MBR8H100MFS, NRVB8H100MFS |
|---|---|
| حجم فایل | 63.17 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
دانلود دیتاشیت MBR8H100MFS, NRVB8H100MFS |
دانلود دیتاشیت |
|---|
سایر مستندات
NRVB8H100MFST1G 6 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi NRVB8H100MFSWFT1G
- Diode Configuration: Single
- Reverse Voltage (Vr): 100V
- Forward Voltage (Vf@If): 810mV@8A
- Reverse Leakage Current (Ir): 60nA@100V
- Average Rectified Current (Io): 8A
- Package: SO-8FL
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 100V
- Current - Average Rectified (Io): 8A
- Voltage - Forward (Vf) (Max) @ If: 900mV @ 8A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 2µA @ 100V
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: 8-PowerTDFN, 5 Leads
- Supplier Device Package: 5-DFN (5x6) (8-SOFL)
- Operating Temperature - Junction: -55°C ~ 175°C
- Base Part Number: NRVB8H1
- detail: Diode Schottky 100V 8A Surface Mount 5-DFN (5x6) (8-SOFL)
