74VHC112MX دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | 74VHC112MX |
|---|---|
| حجم فایل | 72.75 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 9 |
دانلود دیتاشیت 74VHC112MX |
دانلود دیتاشیت |
|---|
سایر مستندات
74VHC112 11 pages
74VHC112MX 9 pages
مشخصات فنی
- RoHS: true
- Type: JK-Type
- Series: 74VHC
- Category: Logic ICs/Flip Flops
- Function: 置位和复位
- Datasheet: onsemi 74VHC112MX
- Output Type: 互补型
- Sink Current: 8mA
- Trigger Type: 下降沿
- Source Current: 8mA
- Supply Voltage: 2V~5.5V
- Clock Frequency: 185MHz
- Input Capacitance: 4pF
- Number of Elements: 2
- Operating Temperature: -40°C~+85°C
- Quiescent Current (Iq): 2uA
- Maximum Propagation Delay: 10.5ns@5V,50pF
- Number of Bits per Element: 1
- Package: SOP-16
- Manufacturer: onsemi
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Max Propagation Delay @ V, Max CL: 10.5ns @ 5V, 50pF
- Current - Output High, Low: 8mA, 8mA
- Voltage - Supply: 2V ~ 5.5V
- Current - Quiescent (Iq): 2µA
- Mounting Type: Surface Mount
- Supplier Device Package: 16-SOIC
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
- Base Part Number: 74VHC112
- detail: Flip Flop 2 Element JK Type 1 Bit Negative Edge 16-SOIC (0.154", 3.90mm Width)
