NCV4294C دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NCV4294C	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: onsemi NCV4294CSN33T1G
Package: TSOP-5-1.5mm
Manufacturer: onsemi
Series: Automotive, AEC-Q100
Packaging: Tape & Reel (TR)
Part Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 45V
Voltage - Output (Min/Fixed): 3.3V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.25V @ 20mA
Current - Output: 30mA
Current - Quiescent (Iq): 170µA
Current - Supply (Max): 4mA
PSRR: 60dB (100Hz)
Control Features: -
Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: SOT-23-5 Thin, TSOT-23-5
Supplier Device Package: 5-TSOP
Base Part Number: NCV4294
detail: Linear Voltage Regulator IC 1 Output 30mA 5-TSOP
