دیتاشیت MCH6436-TL-W
مشخصات دیتاشیت
| نام دیتاشیت |
MCH6436
|
| حجم فایل |
396.284
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi MCH6436-TL-W
-
Operating Temperature:
+150°C@(Tj)
-
Power Dissipation (Pd):
1.5W
-
Total Gate Charge (Qg@Vgs):
7.5nC@4.5V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
710pF@10V
-
Continuous Drain Current (Id):
6A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.3V@1mA
-
Reverse Transfer Capacitance (Crss@Vds):
65pF@10V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
26mΩ@4.5V,3A
-
Package:
SOT-363-6(SC-70-6)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
30V
-
Current - Continuous Drain (Id) @ 25°C:
6A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
1.8V, 4.5V
-
Rds On (Max) @ Id, Vgs:
34mOhm @ 3A, 4.5V
-
Vgs(th) (Max) @ Id:
1.3V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
7.5nC @ 4.5V
-
Vgs (Max):
±12V
-
Input Capacitance (Ciss) (Max) @ Vds:
710pF @ 10V
-
FET Feature:
-
-
Power Dissipation (Max):
1.5W (Ta)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SC-88FL/MCPH6
-
Package / Case:
6-SMD, Flat Leads
-
Base Part Number:
MCH64
-
detail:
N-Channel 30V 6A (Ta) 1.5W (Ta) Surface Mount SC-88FL/MCPH6
