NL17SV02XV5T2G دیتاشیت

NL17SV02XV5T2G

مشخصات دیتاشیت

نام دیتاشیت NL17SV02XV5T2G
حجم فایل 70.711 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت NL17SV02XV5T2G

دانلود دیتاشیت

سایر مستندات

NL17SV02XV5T2 5 pages

مشخصات فنی

  • RoHS: true
  • Series: 17SV
  • Category: Logic ICs/Gates
  • Datasheet: onsemi NL17SV02XV5T2G
  • Sink Current: 24mA
  • Source Current: 24mA
  • Supply Voltage: 0.9V~3.6V
  • Logic Gate Type: NORGate
  • Number of Channels: 1
  • Low Level Range (VIL): 0.7V~0.8V
  • Operating Temperature: -40°C~+85°C
  • High Level Range (VIH): 1.6V~2V
  • Propagation Delay Time: 3.3ns@3V,30pF
  • Quiescent Current (Max): 900nA
  • Package: SOT-553
  • Manufacturer: onsemi
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Logic Type: NOR Gate
  • Number of Circuits: 1
  • Number of Inputs: 2
  • Features: -
  • Voltage - Supply: 0.9V ~ 3.6V
  • Current - Quiescent (Max): 900nA
  • Current - Output High, Low: 24mA, 24mA
  • Logic Level - Low: 0.7V ~ 0.8V
  • Logic Level - High: 1.6V ~ 2V
  • Max Propagation Delay @ V, Max CL: 3.3ns @ 3V, 30pF
  • Mounting Type: Surface Mount
  • Supplier Device Package: SOT-553
  • Package / Case: SOT-553
  • Base Part Number: NL17S
  • detail: NOR Gate IC 1 Channel SOT-553
