NLV27WZ06DFT2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NLV27WZ06DFT2G
|
|
حجم فایل
|
60.936
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
RoHS:
true
-
Series:
27WZ
-
Category:
Logic ICs/Inverters
-
Datasheet:
onsemi NLV27WZ06DFT2G
-
Sink Current:
32mA
-
Number of channels:
2
-
Supply Current (Max):
1uA
-
Max Propagation Delay:
3ns@5V,50pF
-
Operating Temperature:
-55°C~+125°C
-
Supply Voltage(Single):
1.65V~5.5V
-
Package:
SC-88
-
Manufacturer:
onsemi
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Logic Type:
Inverter
-
Number of Circuits:
2
-
Number of Inputs:
2
-
Features:
Open Drain
-
Voltage - Supply:
1.65V ~ 5.5V
-
Current - Quiescent (Max):
1µA
-
Current - Output High, Low:
-, 32mA
-
Logic Level - Low:
-
-
Logic Level - High:
-
-
Max Propagation Delay @ V, Max CL:
3ns @ 5V, 50pF
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SC-88/SC70-6/SOT-363
-
Package / Case:
6-TSSOP, SC-88, SOT-363
-
Base Part Number:
NLV27
-
detail:
Inverter IC 2 Channel Open Drain SC-88/SC70-6/SOT-363
