NSVJ2394SA3T1G دیتاشیت

NSVJ2394SA3T1G

مشخصات دیتاشیت

نام دیتاشیت NSVJ2394SA3T1G
حجم فایل 54.56 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت NSVJ2394SA3T1G

دانلود دیتاشیت

سایر مستندات

NSVJ2394SA3 5 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/JFETs
  • FET Type: N-Channel
  • Datasheet: onsemi NSVJ2394SA3T1G
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Input Capacitance (Ciss@Vds): 10pF@5V
  • Total Device Dissipation (Pd): 200mW
  • Drain Current (Idss@Vds,Vgs=0): 32mA@5V
  • Gate-Source Breakdown Voltage (V(BR)GSS): 15V
  • Gate-Source Cutoff Voltage (VGS(off)@ID): 700mV@100uA
  • Package: SC-59
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Voltage - Breakdown (V(BR)GSS): 15V
  • Drain to Source Voltage (Vdss): 15V
  • Current - Drain (Idss) @ Vds (Vgs=0): 32mA @ 5V
  • Current Drain (Id) - Max: 50mA
  • Voltage - Cutoff (VGS off) @ Id: 700mV @ 100µA
  • Input Capacitance (Ciss) (Max) @ Vds: 10pF @ 5V
  • Power - Max: 200mW
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SC-59-3/CP3
  • Base Part Number: NSVJ23
  • detail: JFET N-Channel 15V 50mA 200mW Surface Mount SC-59-3/CP3
