دیتاشیت EGP20F

EGP20A - EGP20K

مشخصات دیتاشیت

نام دیتاشیت EGP20A - EGP20K
حجم فایل 389.234 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت EGP20A - EGP20K

EGP20A - EGP20K Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - General Purpose
  • Datasheet: onsemi EGP20F
  • Diode Configuration: -
  • Reverse Voltage (Vr): 300V
  • Forward Voltage (Vf@If): 1.25V@2A
  • Reverse Leakage Current: 5uA@300V
  • Average Rectified Current (Io): 2A
  • Package: DO-204
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 300V
  • Current - Average Rectified (Io): 2A
  • Voltage - Forward (Vf) (Max) @ If: 1.25V @ 2A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 50ns
  • Current - Reverse Leakage @ Vr: 5µA @ 300V
  • Capacitance @ Vr, F: 45pF @ 4V, 1MHz
  • Mounting Type: Through Hole
  • Package / Case: DO-204AC, DO-15, Axial
  • Supplier Device Package: DO-15
  • Operating Temperature - Junction: -65°C ~ 150°C
  • Base Part Number: EGP20
  • detail: Diode Standard 300V 2A Through Hole DO-15
