NTGS3433T1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NTGS3433T1G
|
|
حجم فایل
|
90.703
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi NTGS3433T1G
-
Package:
SOT-23-6
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
FET Type:
P-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
12V
-
Current - Continuous Drain (Id) @ 25°C:
2.35A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
2.5V, 4.5V
-
Rds On (Max) @ Id, Vgs:
75mOhm @ 3.3A, 4.5V
-
Vgs(th) (Max) @ Id:
1.5V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
15nC @ 4.5V
-
Vgs (Max):
±8V
-
Input Capacitance (Ciss) (Max) @ Vds:
550pF @ 5V
-
FET Feature:
-
-
Power Dissipation (Max):
500mW (Ta)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
6-TSOP
-
Package / Case:
SOT-23-6
-
Base Part Number:
NTGS34
-
detail:
P-Channel 12V 2.35A (Ta) 500mW (Ta) Surface Mount 6-TSOP
