LM385Z-2.5RPG 数据手册
其他文档
LM285, LM385B 9 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: onsemi LM385Z-2.5RPG
- Tolerance: ±3%
- Output Type: Fixed
- Input Voltage: -
- Output Current: 20mA
- Output Voltage: 2.5V
- Reference Type: parallel connection
- Supply Current: -
- Noise - 10Hz to 10kHz: 120uVrms
- Operating Temperature: 0°C~+70°C@(Ta)
- Noise - 1/10Hz to 10Hz: -
- Temperature Coefficient: 80ppm/°C
- Package: TO-92-3
- Manufacturer: onsemi
- Series: -
- Packaging: Tape & Box (TB)
- Part Status: Obsolete
- Voltage - Output (Min/Fixed): 2.5V
- Current - Output: 20mA
- Noise - 0.1Hz to 10Hz: -
- Voltage - Input: -
- Current - Supply: -
- Current - Cathode: 30µA
- Mounting Type: Through Hole
- Package / Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- Supplier Device Package: TO-92-3
- Base Part Number: LM385
- detail: Shunt Voltage Reference IC ±3% TO-92-3
