دیتاشیت MC33761

MC33761

مشخصات دیتاشیت

نام دیتاشیت MC33761
حجم فایل 412.158 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

MC33761

دانلود دیتاشیت

سایر مستندات

MC33761SNT1-050G 14 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi MC33761SNT1-029G
  • Package: TSOP-5-1.5mm
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 12V
  • Voltage - Output (Min/Fixed): 2.9V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.25V @ 80mA
  • Current - Output: 80mA
  • Current - Quiescent (Iq): 180µA
  • PSRR: 70dB (1kHz)
  • Control Features: Enable
  • Protection Features: Antisaturation, Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Supplier Device Package: 5-TSOP
  • Base Part Number: MC33761
  • detail: Linear Voltage Regulator IC 1 Output 80mA 5-TSOP
