NLVVHCT125ADTRG دیتاشیت

NLVVHCT125ADTRG

مشخصات دیتاشیت

نام دیتاشیت NLVVHCT125ADTRG
حجم فایل 81.572 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

مشاهده دیتاشیت NLVVHCT125ADTRG

دانلود دیتاشیت

سایر مستندات

MC74VHCT125A 7 pages

مشخصات فنی

  • RoHS: true
  • Category: Logic ICs/Buffer/Driver/Transceiver
  • Datasheet: onsemi NLVVHCT125ADTRG
  • Input type: -
  • output type: Tri-State
  • Sink Current: 8mA
  • Source Current: 8mA
  • Supply Voltage: 2V~5.5V
  • Number of Elements: 4
  • Operating Temperature: -55°C~+125°C
  • Number of Bits per Element: 1
  • Package: TSSOP-14
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Logic Type: Buffer, Non-Inverting
  • Current - Output High, Low: 8mA, 8mA
  • Voltage - Supply: 2V ~ 5.5V
  • Mounting Type: Surface Mount
  • Package / Case: 14-TSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 14-TSSOP
  • Base Part Number: NLVVHCT
  • detail: Buffer, Non-Inverting 4 Element 1 Bit per Element 3-State Output 14-TSSOP
