NHP620MFDT3G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NHP620MFDT3G |
|---|---|
| حجم فایل | 83.588 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت NHP620MFDT3G |
دانلود دیتاشیت |
|---|
سایر مستندات
NHP620MFD, NRVHP620MFD 5 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Diodes - General Purpose
- Datasheet: onsemi NHP620MFDT3G
- Diode Configuration: 2 Independent
- Reverse Voltage (Vr): 200V
- Forward Voltage (Vf@If): 1.02V@6A
- Reverse Leakage Current: 500nA@200V
- Average Rectified Current (Io): 3A
- Package: DFN-8(5x6)
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 200V
- Current - Average Rectified (Io) (per Diode): 3A
- Voltage - Forward (Vf) (Max) @ If: 1V @ 3A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 25ns
- Current - Reverse Leakage @ Vr: 500nA @ 200V
- Operating Temperature - Junction: -55°C ~ 175°C
- Mounting Type: Surface Mount
- Package / Case: 8-PowerTDFN
- Supplier Device Package: 8-DFN (5x6) Dual Flag (SO8FL-Dual)
- Base Part Number: NHP620
- detail: Diode Array 2 Independent Standard 200V 3A Surface Mount 8-PowerTDFN
