NCV8718 دیتاشیت

NCV8718

مشخصات دیتاشیت

نام دیتاشیت NCV8718
حجم فایل 298.541 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

مشاهده دیتاشیت NCV8718

دانلود دیتاشیت

سایر مستندات

NCV8718BMT500TBG 8 pages

مشخصات فنی

  • RoHS: true
  • Feature: Overcurrent Protection;Thermal Protection;Soft start
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV8718AMTADJTBG
  • Output Type: Adjustable
  • Output Current: 300mA
  • Output Voltage: 1.2V~5V
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 24V
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Quiescent Current (Ground Current): 8uA
  • Power Supply Rejection Ratio (PSRR): 70dB@(100Hz)
  • Package: WDFN-6
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 24V
  • Voltage - Output (Min/Fixed): 1.2V
  • Voltage - Output (Max): 5V
  • Voltage Dropout (Max): -
  • Current - Output: 300mA
  • Current - Quiescent (Iq): 8µA
  • Current - Supply (Max): 300µA
  • PSRR: 70dB ~ 35dB (100Hz ~ 100kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature, Soft Start
  • Mounting Type: Surface Mount
  • Package / Case: 6-WDFN Exposed Pad
  • Supplier Device Package: 6-WDFN (2x2)
  • Base Part Number: NCV8718
  • detail: Linear Voltage Regulator IC 1 Output 300mA 6-WDFN (2x2)
