NUS2401SNT1G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MUS2401SNT1	دانلود دیتاشیت

مستندات دیگری یافت نشد!

RoHS: true
Category: Triode/MOS Tube/Transistor/Digital Transistors
Transistor Type: 2PCSNPN,1PCSPNP-预偏置
Collector Current (Ic): 200mA
Power Dissipation (Pd): 350mW
Transition Frequency (fT): -
DC Current Gain (hFE@Ic,Vce): -
Collector Cut-Off Current (Icbo): 500nA
Collector-Emitter Breakdown Voltage (Vceo): 50V
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 250mV@10mA,1mA;250mV@10mA,300uA
Package: SC-74-6
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Obsolete
Current - Collector (Ic) (Max): 200mA
Voltage - Collector Emitter Breakdown (Max): 50V
Resistor - Base (R1): 175Ohms, 10kOhms
Resistor - Emitter Base (R2): 10kOhms
DC Current Gain (hFE) (Min) @ Ic, Vce: -
Vce Saturation (Max) @ Ib, Ic: 250mV @ 1mA, 10mA / 250mV @ 300µA, 10mA
Current - Collector Cutoff (Max): 500nA
Frequency - Transition: -
Power - Max: 350mW
Mounting Type: Surface Mount
Package / Case: SC-74, SOT-457
Supplier Device Package: SC-74
Base Part Number: NUS2401
detail: Pre-Biased Bipolar Transistor (BJT) 2 NPN, 1 PNP - Pre-Biased 50V 200mA 350mW Surface Mount SC-74
