دیتاشیت FDMC0310AS-F127

FDMC0310AS

مشخصات دیتاشیت

نام دیتاشیت FDMC0310AS
حجم فایل 1131.811 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت FDMC0310AS

FDMC0310AS Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi FDMC0310AS-F127
  • Total Gate Charge (Qg@Vgs): 52nC@10V
  • Drain Source Voltage (Vdss): 30V
  • Input Capacitance (Ciss@Vds): 3165pF@15V
  • Continuous Drain Current (Id): 21A
  • Gate Threshold Voltage (Vgs(th)@Id): 3V@1mA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 4.4mΩ@19A,10V
  • Package: WDFN-8
  • Manufacturer: onsemi
  • Series: PowerTrench®, SyncFET™
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 30V
  • Current - Continuous Drain (Id) @ 25°C: 21A (Tc)
  • Rds On (Max) @ Id, Vgs: 4.4mOhm @ 19A, 10V
  • Vgs(th) (Max) @ Id: 3V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 52nC @ 10V
  • Input Capacitance (Ciss) (Max) @ Vds: 3165pF @ 15V
  • FET Feature: -
  • Mounting Type: Surface Mount
  • Supplier Device Package: 8-MLP (3.3x3.3)
  • Package / Case: 8-PowerWDFN
  • Base Part Number: FDMC03
  • detail: N-Channel 30V 21A (Tc) Surface Mount 8-MLP (3.3x3.3)
