دیتاشیت VEC2616-TL-H-Z-W
مشخصات دیتاشیت
| نام دیتاشیت |
VEC2616
|
| حجم فایل |
1103.434
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
FET Type:
N and P-Channel
-
FET Feature:
Logic Level Gate
-
Drain to Source Voltage (Vdss):
60V
-
Current - Continuous Drain (Id) @ 25°C:
3A, 2.5A
-
Rds On (Max) @ Id, Vgs:
80mOhm @ 1.5A, 10V
-
Vgs(th) (Max) @ Id:
2.6V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
10nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
505pF @ 20V
-
Power - Max:
1W
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SMD, Flat Lead
-
Supplier Device Package:
SOT-28FL/VEC8
-
Base Part Number:
VEC2616
-
detail:
Mosfet Array N and P-Channel 60V 3A, 2.5A 1W Surface Mount SOT-28FL/VEC8
