- دیتاشیت NCV78L12ABPG
دیتاشیت NCV78L12ABPG
مشخصات دیتاشیت
| نام دیتاشیت | NCV78L12ABPG |
|---|---|
| حجم فایل | 87.177 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 19 |
NCV78L12ABPG |
دانلود دیتاشیت |
|---|
سایر مستندات
MC78L00A Series, NCV7800A Datasheet 15 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi NCV78L12ABPG
- Package: TO-92-3
- Manufacturer: onsemi
- Series: Automotive, AEC-Q100
- Packaging: Bulk
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 35V
- Voltage - Output (Min/Fixed): 12V
- Voltage - Output (Max): -
- Voltage Dropout (Max): -
- Current - Output: 100mA
- Current - Quiescent (Iq): 6.5mA
- PSRR: 42dB (120Hz)
- Control Features: -
- Protection Features: Over Temperature, Short Circuit
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Through Hole
- Package / Case: TO-226-3, TO-92-3 (TO-226AA)
- Supplier Device Package: TO-92-3
- Base Part Number: NCV78
- detail: Linear Voltage Regulator IC 1 Output 100mA TO-92-3
