مشاهده دیتاشیت FDZ1905PZ	دانلود دیتاشیت

مستندات دیگری یافت نشد!

RoHS: true
Type: 2PCSPChannel(Common Drain)
Category: Triode/MOS Tube/Transistor/MOSFETs
Datasheet: onsemi FDZ1905PZ
Operating Temperature: -55°C~+150°C@(Tj)
Power Dissipation (Pd): 900mW
Total Gate Charge (Qg@Vgs): -
Drain Source Voltage (Vdss): -
Input Capacitance (Ciss@Vds): -
Continuous Drain Current (Id): -
Gate Threshold Voltage (Vgs(th)@Id): 1V@250uA
Reverse Transfer Capacitance (Crss@Vds): -
Drain Source On Resistance (RDS(on)@Vgs,Id): 126mΩ@1A,4.5V
Package: WLCSP-6(1.5x1x0.6)
Manufacturer: onsemi
Series: PowerTrench®
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
FET Type: 2 P-Channel (Dual)
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): -
Current - Continuous Drain (Id) @ 25°C: -
Rds On (Max) @ Id, Vgs: 126mOhm @ 1A, 4.5V
Vgs(th) (Max) @ Id: 1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: -
Input Capacitance (Ciss) (Max) @ Vds: -
Power - Max: 900mW
Mounting Type: Surface Mount
Package / Case: 6-UFBGA, WLCSP
Supplier Device Package: 6-WLCSP (1.0x1.5)
Base Part Number: FDZ19
detail: Mosfet Array 2 P-Channel (Dual) 900mW Surface Mount 6-WLCSP (1.0x1.5)
