دیتاشیت CM1442-08CP
مشخصات دیتاشیت
| نام دیتاشیت |
CM1442
|
| حجم فایل |
546.908
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
11
|
مشخصات
-
RoHS:
true
-
Category:
Bead/Filter/EMI Optimization/EMI Filters (LC, RC Networks)
-
Datasheet:
onsemi CM1442-08CP
-
Capacitance:
15pF
-
Filter Order:
2
-
ESD Protection:
Yes
-
Attenuation Value:
30dB@1GHz
-
Number of Channels:
8
-
OperatingTemperature:
-40°C~+85°C
-
Frequency - Cutoff or Center:
115MHz
-
Package:
CSP-20
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Type:
Low Pass
-
Technology:
RC (Pi)
-
Center / Cutoff Frequency:
115MHz (Cutoff)
-
Resistance - Channel (Ohms):
100
-
Values:
R = 100Ohms, C = 15pF
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
Data Lines for Mobile Devices
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
20-WFBGA, WLCSP
-
Size / Dimension:
0.124" L x 0.041" W (3.16mm x 1.05mm)
-
Height:
0.028" (0.70mm)
-
Base Part Number:
CM1442
-
detail:
RC (Pi) EMI Filter 2nd Order Low Pass 8 Channel R = 100Ohms, C = 15pF 20-WFBGA, WLCSP
