دیتاشیت NLV14053BDR2G

NLV14053BDR2G

مشخصات دیتاشیت

نام دیتاشیت NLV14053BDR2G
حجم فایل 90.84 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

NLV14053BDR2G

دانلود دیتاشیت

سایر مستندات

MC14051B, 52B, 53B 11 pages

مشخصات فنی

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
  • Datasheet: onsemi NLV14053BDR2G
  • Supply Voltage: 3V~18V
  • Switch Circuit: SPDT(SPDT)
  • Number of Channels: 3
  • On-State Resistance (Max): 280Ω
  • Package: SOP-16
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Multiplexer/Demultiplexer Circuit: 2:1
  • Number of Circuits: 3
  • Channel-to-Channel Matching (ΔRon): 10Ohm
  • Voltage - Supply, Single (V+): 3V ~ 18V
  • Voltage - Supply, Dual (V±): -
  • Switch Time (Ton, Toff) (Max): -
  • -3db Bandwidth: 17MHz
  • Charge Injection: -
  • Channel Capacitance (CS(off), CD(off)): 7.5pF
  • Current - Leakage (IS(off)) (Max): 100nA
  • Crosstalk: -
  • Operating Temperature: -55°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 16-SOIC
  • Base Part Number: NLV1405
  • detail: 3 Circuit IC Switch 2:1 280Ohm 16-SOIC
