NRVHP820LFST1G دیتاشیت

NRVHP820LFST1G

مشخصات دیتاشیت

نام دیتاشیت NRVHP820LFST1G
حجم فایل 84.798 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

مشاهده دیتاشیت NRVHP820LFST1G

دانلود دیتاشیت

سایر مستندات

NHP820LFS, NRVHP820LFS 6 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: onsemi NRVHP820LFST1G
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 200V
  • Operating Temperature: -55°C~+175°C@(Tj)
  • Forward Voltage (Vf@If): 1V@8A
  • Reverse Leakage Current: 1uA@200V
  • Reverse Recovery Time (trr): 35ns
  • Average Rectified Current (Io): 8A
  • Package: LFPAK-4
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 200V
  • Current - Average Rectified (Io): 8A
  • Voltage - Forward (Vf) (Max) @ If: 1V @ 8A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 1µA @ 200V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: SOT-1023, 4-LFPAK
  • Supplier Device Package: 4-LFPAK
  • Operating Temperature - Junction: -55°C ~ 175°C
  • Base Part Number: NRVHP82
  • detail: Diode Standard 200V 8A Surface Mount 4-LFPAK
