- دیتاشیت NCP1247BD065R2G
NCP1247BD065R2G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NCP1247BD065R2G |
|---|---|
| حجم فایل | 92.776 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 44 |
دانلود دیتاشیت NCP1247BD065R2G |
دانلود دیتاشیت |
|---|
سایر مستندات
NCP1247 Datasheet 42 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/AC-DC Controllers & Regulators
- Topology: Flyback
- Datasheet: onsemi NCP1247BD065R2G
- Duty Cycle: 80%
- Supply Voltage: 8.9V~28V
- Output Isolation: Isolation
- Switching Frequency: 65kHz
- Operating Temperature: -40°C~+150°C@(Tj)
- Package: SOP-7
- Manufacturer: onsemi
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Internal Switch(s): No
- Voltage - Breakdown: -
- Voltage - Start Up: 12V
- Voltage - Supply (Vcc/Vdd): 8.9V ~ 28V
- Frequency - Switching: 65kHz
- Fault Protection: Current Limiting, Over Load, Over Power, Over Temperature, Over Voltage
- Control Features: -
- Package / Case: 8-SOIC (0.154", 3.90mm Width), 7 Leads
- Supplier Device Package: 7-SOIC
- Mounting Type: Surface Mount
- Base Part Number: NCP1247
- detail: Converter Offline Flyback Topology 65kHz 7-SOIC
