NCV8716MT30TBG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCV8716MT30TBG
|
|
حجم فایل
|
68.776
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
19
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCV8716MT30TBG
-
Package:
DFN-6(2x2)
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
24V
-
Voltage - Output (Min/Fixed):
3V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.58V @ 80mA
-
Current - Output:
80mA
-
Current - Quiescent (Iq):
5.8µA
-
PSRR:
58dB (100kHz)
-
Control Features:
-
-
Protection Features:
Over Current, Over Temperature, Under Voltage Lockout (UVLO)
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
6-WFDFN Exposed Pad
-
Supplier Device Package:
6-WDFN (2x2)
-
Base Part Number:
NCV8716
-
detail:
Linear Voltage Regulator IC 1 Output 80mA 6-WDFN (2x2)
