MC74ACT564DWR2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MC74ACT564DWR2G
|
|
حجم فایل
|
68.058
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Type:
D-Type
-
Series:
74ACT
-
Category:
Logic ICs/Flip Flops
-
Function:
Standard
-
Datasheet:
onsemi MC74ACT564DWR2G
-
Output Type:
Tri-State;Inverted
-
Sink Current:
24mA
-
Trigger Type:
上升沿
-
Source Current:
24mA
-
Supply Voltage:
4.5V~5.5V
-
Clock Frequency:
85MHz
-
Input Capacitance:
4.5pF
-
Quiescent Current (Iq):
8uA
-
Maximum Propagation Delay:
10.5ns@5V,50pF
-
Package:
SOP-20-300mil
-
Manufacturer:
onsemi
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Number of Elements:
1
-
Number of Bits per Element:
8
-
Max Propagation Delay @ V, Max CL:
10.5ns @ 5V, 50pF
-
Current - Output High, Low:
24mA, 24mA
-
Voltage - Supply:
4.5V ~ 5.5V
-
Current - Quiescent (Iq):
8µA
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
20-SOIC
-
Package / Case:
20-SOIC (0.295", 7.50mm Width)
-
Base Part Number:
MC74ACT564
-
detail:
Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-SOIC (0.295", 7.50mm Width)
