دیتاشیت MC33275MN-2.5R2G
مشخصات دیتاشیت
| نام دیتاشیت | MC33275, NCV33275 |
|---|---|
| حجم فایل | 236.431 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
دانلود دیتاشیت MC33275, NCV33275 |
MC33275, NCV33275 Datasheet |
|---|
مشخصات
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 13V
- Voltage - Output (Min/Fixed): 2.5V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.5V @ 300mA
- Current - Output: 300mA
- Current - Quiescent (Iq): 200µA
- PSRR: 75dB (120Hz)
- Control Features: -
- Protection Features: Over Current, Over Temperature
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 8-VDFN Exposed Pad
- Supplier Device Package: 8-DFN (4x4)
- Base Part Number: MC33275
- detail: Linear Voltage Regulator IC 1 Output 300mA 8-DFN (4x4)
