دیتاشیت NCV4266-2CST33T3G
مشخصات دیتاشیت
| نام دیتاشیت | NCV4266-2C |
|---|---|
| حجم فایل | 230.583 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 13 |
دانلود دیتاشیت NCV4266-2C |
NCV4266-2C Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: onsemi NCV4266-2CST33T3G
- Output Current: 150mA
- Output Voltage: 3.3V
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 45V
- Operating Temperature: -40°C~+150°C
- Quiescent Current (Ground Current): 60uA
- Power Supply Rejection Ratio (PSRR): 68dB@(100Hz)
- Package: SOT-223
- Manufacturer: onsemi
- Series: Automotive, AEC-Q100
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 45V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Voltage Dropout (Max): -
- Current - Output: 150mA
- Current - Quiescent (Iq): 60µA
- Current - Supply (Max): 4mA
- PSRR: 68dB (100Hz)
- Control Features: Enable
- Protection Features: Over Temperature, Reverse Polarity, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: TO-261-5, TO-261AB
- Supplier Device Package: SOT-223 (TO-261)
- Base Part Number: NCV4266
- detail: Linear Voltage Regulator IC 1 Output 150mA SOT-223 (TO-261)
