NCV8411DTRKG دیتاشیت

NCV8411DTRKG

مشخصات دیتاشیت

نام دیتاشیت NCV8411DTRKG
حجم فایل 76.3 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

مشاهده دیتاشیت NCV8411DTRKG

دانلود دیتاشیت

سایر مستندات

NCV8411 11 pages

مشخصات فنی

  • RoHS: true
  • Type: -
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi NCV8411DTRKG
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Power Dissipation (Pd): -
  • Total Gate Charge (Qg@Vgs): -
  • Drain Source Voltage (Vdss): -
  • Input Capacitance (Ciss@Vds): -
  • Continuous Drain Current (Id): -
  • Gate Threshold Voltage (Vgs(th)@Id): -
  • Reverse Transfer Capacitance (Crss@Vds): -
  • Drain Source On Resistance (RDS(on)@Vgs,Id): -
  • Package: TO-252
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Switch Type: General Purpose
  • Number of Outputs: 1
  • Ratio - Input:Output: 1:1
  • Output Configuration: Low Side
  • Output Type: N-Channel
  • Interface: On/Off
  • Voltage - Load: 42V (Max)
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 45A
  • Rds On (Typ): 23mOhm
  • Input Type: CMOS
  • Features: -
  • Fault Protection: Current Limiting (Fixed), Over Temperature, Over Voltage
  • Mounting Type: Surface Mount
  • Supplier Device Package: DPAK
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Base Part Number: NCV8411
  • detail: Power Switch/Driver 1:1 N-Channel 45A DPAK
