FDPF7N60NZT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
FDPF7N60NZT
|
|
حجم فایل
|
68.843
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
11
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi FDPF7N60NZT
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
33W
-
Total Gate Charge (Qg@Vgs):
17nC@10V
-
Input Capacitance (Ciss@Vds):
730pF@25V
-
Continuous Drain Current (Id):
6.5A
-
Gate Threshold Voltage (Vgs(th)@Id):
5V@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
1.25Ω@3.25A,10V
-
Package:
TO-220
-
Manufacturer:
onsemi
-
Series:
UniFET-II™
-
Packaging:
Tube
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
600V
-
Current - Continuous Drain (Id) @ 25°C:
6.5A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
1.25Ohm @ 3.25A, 10V
-
Vgs(th) (Max) @ Id:
5V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
17nC @ 10V
-
Vgs (Max):
±30V
-
Input Capacitance (Ciss) (Max) @ Vds:
730pF @ 25V
-
FET Feature:
-
-
Power Dissipation (Max):
33W (Tc)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
TO-220F
-
Package / Case:
TO-220-3 Full Pack
-
Base Part Number:
FDPF7
-
detail:
N-Channel 600V 6.5A (Tc) 33W (Tc) Through Hole TO-220F
