NCV8182CDTRKG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NCV8182CDTRKG	دانلود دیتاشیت

NCV8182C 12 pages

RoHS: true
Feature: Overcurrent Protection;Thermal Protection;Reverse connection protection
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: onsemi NCV8182CDTRKG
Output Type: Adjustable
Output Current: 200mA
Dropout Voltage: 0.5V@(200mA)
Output Polarity: positive
Number of Outputs: 1
Maximum Input Voltage: 35V
Operating Temperature: -40°C~+150°C@(Tj)
Quiescent Current (Ground Current): 150uA
Power Supply Rejection Ratio (PSRR): 85dB@(100Hz)
Package: DPAK-5
Manufacturer: onsemi
Series: Automotive, AEC-Q100
Packaging: Tape & Reel (TR)
Part Status: Active
Output Configuration: Positive
Number of Regulators: 1
Voltage - Input (Max): 35V
Voltage - Output (Min/Fixed): Tracking
Voltage - Output (Max): -
Voltage Dropout (Max): 0.5V @ 200mA
Current - Output: 200mA
Current - Quiescent (Iq): 150µA
Current - Supply (Max): 15mA
PSRR: 85dB (100Hz)
Control Features: Enable
Protection Features: Over Current, Over Temperature, Reverse Polarity
Mounting Type: Surface Mount
Package / Case: TO-252-5, DPak (4 Leads + Tab), TO-252AD
Supplier Device Package: DPAK-5
Base Part Number: NCV8182
detail: Linear Voltage Regulator IC 1 Output 200mA DPAK-5
