FCD260N65S3 دیتاشیت

FCD260N65S3

مشخصات دیتاشیت

نام دیتاشیت FCD260N65S3
حجم فایل 66.414 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

مشاهده دیتاشیت FCD260N65S3

دانلود دیتاشیت

سایر مستندات

FCD260N65S3 10 pages

مشخصات فنی

  • RoHS: true
  • Type: N Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi FCD260N65S3
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 90W
  • Total Gate Charge (Qg@Vgs): 24nC@10V
  • Drain Source Voltage (Vdss): 650V
  • Input Capacitance (Ciss@Vds): 1010pF@400V
  • Continuous Drain Current (Id): 12A
  • Gate Threshold Voltage (Vgs(th)@Id): 4.5V@1.2mA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 260mΩ@10V,6A
  • Package: TO-252
  • Manufacturer: onsemi
  • Series: SuperFET® III
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 650V
  • Current - Continuous Drain (Id) @ 25°C: 12A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 260mOhm @ 6A, 10V
  • Vgs(th) (Max) @ Id: 4.5V @ 1.2mA
  • Gate Charge (Qg) (Max) @ Vgs: 24nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 1010pF @ 400V
  • FET Feature: -
  • Power Dissipation (Max): 90W (Tc)
  • Mounting Type: Surface Mount
  • Supplier Device Package: TO-252, (D-Pak)
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Base Part Number: FCD26
  • detail: N-Channel 650V 12A (Tc) 90W (Tc) Surface Mount TO-252, (D-Pak)
