دیتاشیت LV5768V-A-TLM-E

LV5768V

مشخصات دیتاشیت

نام دیتاشیت LV5768V
حجم فایل 452.329 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

دانلود دیتاشیت LV5768V

LV5768V Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Controllers
  • Datasheet: onsemi LV5768V-A-TLM-E
  • Package: SSOP-16-4.4mm
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Output Type: Transistor Driver
  • Function: Step-Down
  • Output Configuration: Positive
  • Topology: Buck
  • Number of Outputs: 1
  • Output Phases: 1
  • Voltage - Supply (Vcc/Vdd): 8.5V ~ 42V
  • Frequency - Switching: 80kHz ~ 500kHz
  • Duty Cycle (Max): 90%
  • Synchronous Rectifier: Yes
  • Clock Sync: No
  • Serial Interfaces: -
  • Control Features: Current Limit, Enable, Frequency Control, Soft Start
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 16-LSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 16-SSOP
  • Base Part Number: LV576
  • detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 16-SSOP
