- دیتاشیت NCV1077CSTBT3G
NCV1077CSTBT3G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | NCV1077CSTBT3G |
|---|---|
| حجم فایل | 104.469 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 31 |
دانلود دیتاشیت NCV1077CSTBT3G |
دانلود دیتاشیت |
|---|
سایر مستندات
NCV1070-72_75-77 29 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/AC-DC Controllers & Regulators
- Datasheet: onsemi NCV1077CSTBT3G
- Package: TO-252-3
- Manufacturer: onsemi
- Series: Automotive, AEC-Q100
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Isolation: Non-Isolated
- Internal Switch(s): Yes
- Voltage - Breakdown: 670V
- Topology: Flyback
- Voltage - Start Up: 8.1V
- Voltage - Supply (Vcc/Vdd): 7.7V ~ 8.5V
- Duty Cycle: 69%
- Frequency - Switching: 100kHz
- Power (Watts): 25W
- Fault Protection: Current Limiting, Over Load, Over Voltage, Short Circuit
- Control Features: EN, Frequency Control, Soft Start
- Operating Temperature: -40°C ~ 125°C (TJ)
- Package / Case: TO-261-4, TO-261AA
- Supplier Device Package: SOT-223 (TO-261)
- Mounting Type: Surface Mount
- Base Part Number: NCV1077
- detail: Converter Offline Flyback Topology 100kHz SOT-223 (TO-261)
