NL5S4157ADFT2G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NL5S4157ADFT2G	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: onsemi NL5S4157ADFT2G
Turn-on time: 20ns
Turn-off time: 15ns
Supply Voltage: 1.65V~5.5V
Switch Circuit: SPDT(SPDT)
Number of Channels: 1
On-State Resistance (Max): 800mΩ
Package: SC-88
Manufacturer: onsemi
Series: -
Part Status: Active
Multiplexer/Demultiplexer Circuit: 2:1
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): 40mOhm
Voltage - Supply, Single (V+): 1.65V ~ 5.5V
Voltage - Supply, Dual (V±): 1.65V ~ 5.5V
Switch Time (Ton, Toff) (Max): 20ns, 15ns
-3db Bandwidth: 57MHz
Charge Injection: 55pC
Channel Capacitance (CS(off), CD(off)): 23pF
Current - Leakage (IS(off)) (Max): 10nA
Crosstalk: -66dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 6-TSSOP, SC-88, SOT-363
Supplier Device Package: SC-88/SC70-6/SOT-363
detail: 1 Circuit IC Switch 2:1 800mOhm SC-88/SC70-6/SOT-363
